Slope explosion-proof valve

Brand：Pneumatic eccentric butterfly valve 型號：FBF-1

斜面防爆閥is a safety relief device used for pipeline systems or equipment, which prevents the expansion of explosion accidents through automatic venting. Its main characteristics and applications are as follows:

1、 Core structure and working principle
Component composition
Composed of valve body, rupture disc, clamp, valve cover, and heavy hammer. The rupture disc is made of aluminum alloy or stainless steel material. After being compressed and ruptured, the valve cover pops up to release pressure and is reset by gravity or magnetic force.
Trigger mechanism
When the system pressure exceeds the set value (usually ≥ 0.1MPa), the rupture disc instantly ruptures to release pressure and avoid equipment explosion.
2、 Technical parameters and types
Typical Range of Parameter Items Applicable Scenarios
Nominal diameter DN200-DN800mm dust removal pipeline and flue system
Enduring pressure of 0.1-0.6MPa in dust/gas environment
Working temperature -20 ℃~395 ℃ (magnetic) boiler, power system
Installation angle at any angle (horizontal/vertical) on the top of the flue or the side wall of the cylinder
3、 Application Fields
Industrial safety protection:
Suitable for coal grinding systems, flammable gas warehouses, as well as dust pipelines in building materials, metallurgy, and chemical industries.
Boiler explosion prevention:
Install in the boiler flue of thermal power plants to prevent excessive negative pressure from causing furnace collapse.
4、 Key points for installation and selection
Installation requirements
The distance between adjacent valves should be ≥ 200mm. They should be installed vertically on the cylinder and horizontally on the top.
Selection criteria
Choose carbon steel/stainless steel valve body based on the characteristics of the medium (such as gas, dust); High temperature environment requires magnetic self resetting model.
5、 Typical product series
FBF series: including inclined mouth (FBF-I), flat mouth (FBF-II) and other models, supporting customized flange connection or welding.
Self closing explosion-proof valve: equipped with automatic sealing function after instantaneous pressure relief, reducing downtime.
Note: It is necessary to regularly check the integrity of the rupture disc to ensure that the pressure response accuracy meets the requirements of the working conditions.
注：需定期檢查爆破膜完整性，確保壓力響應精度符合工況需求。
